Beschrijving

Jablotron 100 JA-110P

The JA-110P is a BUS PIR motion detector designed for indoor protection. It detects the movement of an object with the temperature of the human body. The detection properties can be optimized using alternative lenses, such as the: JS-7904 corridor lens, JS-7906 horizontal cap lens and the JS-7901 vertical curtain lens. The immunity level is adjustable and has two different levels. The alarm memory function is an optional setting, this function makes indication and locating an alarm very easy. It is possible to assign the detector to a zone and it only occupies one position in the alarm system. SMART MEMORY indication (SMI) provides visual LED verification of an activated detector. SMI can be switched off using the code control panel. • Power supply: via the control panel BUS, 12V (9 – 15 V) • Standby power consumption: 5 mA • Installation height: 2.5 meters above the ground • Detection range: 110°/ 12 m (with a standard lens ) • Dimensions: 60 x 97 x 52 mm • Safety class 2 in accordance with EN 50121-1 • Environment in accordance with EN 50131-1: II, indoor • Operating temperature: -10 to 40 °C
